Large Assembled On Site Steel Water Tanks
From 39,000L Up To 350,000L
From 39,000 Litres Up To 350,000 Litres.
When the capacity needs to be large, nothing beats our Bluescope Steel Assembled On Site Steel Water Tanks.
Ranging from 39,000 Litres all the way up to 350,000 Litres, we'll have the perfect water storage solution for your rural, commercial or industrial project.
Please find below further information and a list of our most popular sizes.
39,000 Litres To 150,000 Litres
| Model | Capacity (Litres) | Diameter | Height |
|---|---|---|---|
| LX39 | 39,000 | 4.70m | 2.27m |
| LX54 | 54,000 | 5.50m | 2.27m |
| LX88 | 88,000 | 7.10m | 2.27m |
| LX100 | 100,000 | 7.80m | 2.27m |
| LX130 | 130,000 | 8.63m | 2.27m |
| LX150 | 150,000 | 9.41m | 2.27m |
180,000 Litres To 350,000 Litres
| Model | Capacity (Litres) | Diameter | Height |
|---|---|---|---|
| LX180 | 180,000 | 10.18m | 2.27m |
| LX215 | 215,000 | 10.99m | 2.27m |
| LX246 | 246,000 | 11.77m | 2.27m |
| LX280 | 280,000 | 12.55m | 2.27m |
| LX315 | 315,000 | 13.31m | 2.27m |
| LX350 | 350,000 | 14.09m | 2.27m |
Made To Measure Tanks Also Available. Contact Our Friendly Team Today To Discuss Your Requirement.
Request A Free Quote & Info Pack Now
For a no obligation, free quote on the supply, delivery and assembly of one of our Bluescope Aquaplate Steel Water Tanks, simply complete the short form below. One of our expert team members will respond as soon as possible with a comprehensive quote and information pack for your consideration.
Our large assembled on site Bluescope Steel Water Tanks are available throughout Victoria.
Quote & Info Pack Request Form
Complimentary Inclusions/Features
All of our large assembled on site Bluescope Steel Water Tanks are supplied with the following suite of complimentary fittings.
50mm Outlet & Heavy Duty Ball Valve Tap
Tank Inlet Device (fill point)
100mm PVC Overflow Device
Lockable Access Hatch
Removable Internal/External Access Ladder
Multi-layered Food Grade Liner
Genuine Bluescope Steel Wall & Roof
Hot Dipped Galvanised Roof Trusses
Magnesium Anodes (for corrosion protection)
The above fittings can be located on your tank in the positions of your choosing. Other, tailored, fittings to suit your project are also available upon request.
Tank Colour Choices
All of our Large Assembled On Site Bluescope Steel Water Tanks are available in either a Zincalume finish or one of the following stylish Colorbond™ colours.
Made To Measure Tanks Available
The models listed above are a selection of some of our most popular sizes. One of the benefits of our Assembled On Site Bluescope Steel Water Tanks though is the ability to customise the dimensions to a great degree. Please just let us know if you have a particular diameter and/or height that would ideally suit your project and we'll customise a quote on a suitable tank.
